Roland V-1HD

Specifications Video • Video Processing 4:2:2(Y/Pb/Pr), 8-bit • Input Connectors HDMI INPUT 1-4: Type A(19pins)x 4 *HDCP Supported • Output Connectors HDMI OUTPUT: Type A(19pins) / HDMI PREVIEW: Type A(19pins) *HDCP Supported • Input Formats HDMI: 720/59.94p,720/50p(FORMAT switch = 720p) • HDMI: 1080/59.94i,1080/50i,1080/59.94p, 1080/50p(FORMAT switch = 1080i or 1080p) *The input interlaced video signal is converted to progressive video signal by internal processing. *The video signal frame rate is selected by SETUP parameters (59.94 or 50). • Output Formats HDMI: 720/59.94p,720/50p(FORMAT switch = 720p) • HDMI: 1080/59.94i,1080/50i(FORMAT switch = 1080i) • HDMI: 1080/59.94p,1080/50p(FORMAT switch = 1080p) *The video signal frame rate is selected by SETUP parameters (59.94 or 50). • Video Effects Transition: CUT, MIX (DISSOLVE/FAM/NAM/MOSAIC), WIPE (30 types), TRANSFORMER(11 types) • EFFECTS: NEGATIVE, EMBOSS, COLORIZE, COLORPASS, POSTERIZE, SILHOUETTE, MONOCOLOR, FINDEDGE, FLIP, WH-LUMIKEY@, BK-LUMIKEY@, GR-CHROMAKEY@, BL-CHROMAKEY@, PinP(1/4)@, PinP(1/3)@, PinP(1/2)@, SPLIT(H-STRETCH)@. SPLIT(H-CENTER)@, SPLIT(V-STRETCH)@, SPLIT(V-CENTER)@ *@ marked Effects are effected common to A-BUS and B-BUS. Audio • Audio Processing Sampling rate: 24bit/48kHz • Input Connectors Digital: HDMI INPUT 1–4 (19 pins) x 4 Analog: AUDIO IN (RCA pin type), MIC • (Stereo mini type, plug-in power supported) • Output Connectors Digital: HDMI OUTPUT (HDMI Type A 19 pins), HDMI PREVIEW (HDMI Type A 19 pins) • Analog: AUDIO OUT (RCA pin type), PHONES (Stereo mini type)Input LevelAUDIO IN: -10 dBu • • (Maximum : +8 dBu), MIC: -41 – -13dBu (Maximum : -1 dBu) • Input Impedance AUDIO IN: 15 k ohms, MIC:10 k ohms • Output Level AUDIO OUT: -10 dBu (Maximum : +8 dBu), PHONES: 72mW + 72mW (32 ohms) • Output Impedance AUDIO OUT: 1k ohms, PHONES: 10 ohms • Audio Effects EQ, Delay, Compressor, HPF, Gate, Reverb, Mastering effect OTHERS • Other Connectors USB: B Type (for remote control from PC), MIDI: IN, OUT/THRU • Other Functions MEMORY (8 types), FREEZE (input video captured), BPM SYNC (auto transition synchronized to tempo), OUTPUT FADE (WHITE/BLACK/AUDIO) • Power Supply: AC adaptor • Current Draw: 1.5A • Power Consumption: 18W • Dimensions: 313 (W) x 102 (D) x 59 (H) mm / 12-1/3 (W) x 4 (D) x 2-1/3 (H) inches • Weight: 1.2 kg (excluding AC adaptor) 2 lbs 10-2/5 oz • Accessories Owner’s Manual, AC Adaptor, Power Cord, Cord Hook All specifications and appearances are subject to change.
